Screen printing wooden and aluminum handle Squeegees/Squeegee
Application:
1.Precision Extruded Aluminum Squeegee, light weight yet built to
last a lifetime. Ridges inside the squeegee opening help grip the
rubber firmly with even pressure without piercing the blade or
distorting it.
2.Squeegee is held perfectly straight and flat. The squeegee is
pre-drilled and screwed every three inches.
3.To replace the rubber, simply loosen the screws and insert
replacement rubber.
Features:
1.Aluminum Squeegee available with 60, 70, 80, or triple durometer
blade.
2.Reduces cleanup time.
3.Quick rubber replacement.
4.Precision rubber alignment.
5.Customers size are acceptable.
| Features as below: | Product size | Product color | Hardness |
| Can be customized | Green,red,blue | 60/65/70/75/80/85/90/95 |
| Red & Soft: PU1-PU4 For sparse density mesh and low viscosity ink,
it is ideally used for irregular and non-flat printing substrates. |
| Green & Neutral: PU5-PU6 For higher tension and wide range
intensity mesh as well as high or low viscosity ink. Easy to
control the amount of ink over the mesh to ensure the precision of
finished image. |
| Blue & Hard: PU7-PU10 The maximum tension, the high viscosity, and
low amount of ink over the mesh can ensure the precision of
finished image. The harder the squeegee is, the stronger
solvent-resistant it has. |
The width: 9.5mm-320mm, Thickness: 1mm-30mm. Most commonly used
length: 2540mm (100"), 3200 mm(126"), 3660mm(144"), 4000mm(157").
Water-based bevel squeegee in wooden handle:
Water resistance and strong durability in wooden Handle, commonly
used in manual screen printing. 4inch-51inch.
Application:
Our screen printing squeggee is widely used in the below industry:
1.Textile screen printing machine
2.Ceramic and sanitaryware industry machine
3.Electronic machine
4.Window film industry, scraper film
5.Scraper automible,Car, Truck
6.UV ink industry
7.Glass Industry
Squeegees are an essential tool for screen printing, probably the
most important piece of equipment besides the actual screen!
Shanghai SRING cooperated factory is established in 1988, with
nearly 20 years experience, our factory imported the advance
equipment, raw material from Europe and United states. With more
than 300 skilled workers, the squeegees are well established in the
world market.
A brief description of polyurethane squeegee blade/PU squeegee
blade for silk screen printing
Polyurethane squeegee blade/pu squeegee blade for silk screen
printing is used to force the inks through the screen and help
achieve an even print, it is important factors in getting sharp,
clear Prints.
Polyurethane squeegee blade/pu squeegee blade for silk screen
printing will control ink flow through fine, detaile stencils
increasing resolution and overall print quality.
A blunt or rounded blade edge will cause the ink to smear because
it generally pushes more ink through the mesh.
Some high quality polyurethane squeegee blade/pu squeegee blade for
silk screen printing for screen printing are actually made round or
'bull nosed'. For most standard textile screen printing
applications a rectangular cut edge squeegee is best.
Hardness scope & Color
| Grade | Shore | Color | Common Color Sample |
| PU1 | 45-50 | Transparent | |
| PU2 | 50-55 | Light Yellow | |
| PU3 | 55-60 | Light Red | |
| PU4 | 60-65 | Red | |
| PU5 | 65-70 | Light Green | |
| PU6 | 70-75 | Green | |
| PU7 | 75-80 | Blue | |
| PU8 | 80-85 | Coffee | |
| PU9 | 85-90 | Light Brown | |
| PU10 | 90-95 | Pink | |
Why us:
1.We believe in providing quality not just first time, but every
time.
2.High customer’s satisfaction.
3.Focus on screen printing mesh and filtration cloth since 1983
4.Factory price, Best quality, excellent service( before or after
sale)
5.One-stop service can be provided under request to save your time
and cost.
6.At least 3-4times inspections before goods shipping out, the
sales as the directly person with customers will check the goods
not fixed time and goods.
7.Professional and highly motivated staffs.
