Sewing liquid No. 2 filter bag High dirt holding capacity Corrosion resistance High flow rate

Shanghai Spring Industrial Company Ltd
Contact Now
    Buy cheap Sewing liquid No. 2 filter bag High dirt holding capacity Corrosion resistance High flow rate from wholesalers

    Buy cheap Sewing liquid No. 2 filter bag High dirt holding capacity Corrosion resistance High flow rate from wholesalers
    • Buy cheap Sewing liquid No. 2 filter bag High dirt holding capacity Corrosion resistance High flow rate from wholesalers
    • Buy cheap Sewing liquid No. 2 filter bag High dirt holding capacity Corrosion resistance High flow rate from wholesalers
    • Buy cheap Sewing liquid No. 2 filter bag High dirt holding capacity Corrosion resistance High flow rate from wholesalers

    Sewing liquid No. 2 filter bag High dirt holding capacity Corrosion resistance High flow rate

    Ask Lasest Price
    Brand Name : SPRING
    Model Number : JPP
    Certification : ISO9001
    Price : www.silkscreenmesh.com
    Payment Terms : L/C, T/T, D/P, Western Union, Paypal, Money Gram
    Supply Ability : 10000000m/month
    Delivery Time : 2-5Days
    • Product Details
    • Company Profile

    Sewing liquid No. 2 filter bag High dirt holding capacity Corrosion resistance High flow rate

    Sewing liquid No. 2 filter bag High dirt holding capacity Corrosion resistance High flow rate


    Our company produces a variety of liquid filter bags, nylon mesh liquid filter bags are also very popular with customers, the purchase volume is also relatively large. We offer a wide range of micron grades and materials to choose from. The filter bag is seamed at the bottom and side to prevent pinhole leakage.
    Filter principle:
    The liquid filtration bag of Niijing uses the principle of surface filtration to isolate the particles larger than the mesh of the mesh. The non-deformed monofilament thread is woven into a net according to the specific pattern. The intersection of the wire is welded to increase the strength, and the filtration level is achieved. Absolute accuracy, suitable for high precision requirements in the paint, ink, resin and coating industries, and especially suitable for water-based paints.
    Advantages of nylon filter bags:
    Nylon monofilament can be cleaned repeatedly, saving filtration costs. This type of product is suitable for low precision roughing applications.
    Filter accuracy selection:
    25-1200μm, 25 (500 mesh), 50 (270 mesh), 80 (200 mesh), 100 (140 mesh), 125 (120 mesh), 150 (100 mesh), 200 (76 mesh), 250 (60 mesh) ), 300 (50 mesh), 400 (40 mesh), 600 (30 mesh), 800 (15 mesh), 1000 (7)
    Nylon filter bag application field
    Solid-liquid separation and treatment in the fields of petrochemical, light industrial food, metallurgy, electronics, pharmaceutical, etc.
    In the automotive industry, pre-cleaning, electrophoretic paint, spray rinse water, circulating water, etc.
    Solvent purification treatment, resin treatment and wastewater treatment in the three paint industry
    Product specifications
    TypeWeaveMesh Count
    (cm)
    Mesh Count
    (/inch)
    Wire Diameter
    (um)
    Mesh Opening(um)Open Area
    (%)
    Thickness
    (um)
    PA-4/1950PW4105501950611096
    PA-5/1500PW513500150056998
    PA-6/1267PW615400126758796
    PA-7/1079PW718350107957691
    PA-8/900PW82035090052697
    PA-9/861PW92425086160492
    PA-10/750PW102525075056494
    PA-12/533PW123030053341590
    PA-14/514PW143520051452391
    PA-16/425PW164020042546393
    PA-18/356PW184520035641395
    PA-20/300PW205020030036396
    PA-24/267PW246015026741292
    PA-28/207PW287015020734295
    PA-30/213PW307612021341230
    PA-32/213PW328010021346186
    PA-36/178PW369010017841189
    PA-40/150PW4010010015036192
    PA-44/127PW4411010012731195
    PA-48/128PW481208012838150
    PA-56/119PW56142601194496
    PA-59/109PW591506010942110
    PA-64/96PW64163609638116
    PA-72/89PW7218350894190
    PA-80/75PW8020350753693
    PA-88/71PW8822443713970
    PA-96/61PW9624443613474
    PA-100/57PW10025443573275
    PA-104/53PW10426443533176
    PA-110/48PW11028043482878
    PA-120/40PW12030543402380
    PA-130/34PW13033043341981
    PA-140/33PW14035538332272
    PA-150/28TW15038039281773
    PA-157/25TW15740039251574
    PA-165/30TW16542030302554
    PA-200/21TW20050030211756
    PA-212/8TW212540398375
    PA-240/3TW240600393176
    The above is theoretical data, for your reference only!
